• Compatible with all Click Flow connectors and distribution boxes within the
range. Can be controlled by up to 32 transmitting devices.
• Will dim up to 160W of most dimmable LED's, CFLi's, mains and low-voltage halogen
with a dimmable transformer as well as standard tungsten filament
• Load selection control. For LED sources, either LED or capacitive load can
be selected providing a higher percentage of compatibility
• Rotary 'trim' control gives adjustment so the lights can remain slightly ON
and also erradicate flickering which may occur at the bottom end of dimming
• 7 programmable functions: 6 various dimming functions plus ON/OFF
• Easy operation: short press will turn the light ON or OFF, a long press
dims the lights UP or DOWN to the required level
• Electronic over-voltage protection - switches off the output when the
dimmer is overloaded or open circuit
| Technical Details | |
|---|---|
| Supply voltage: | 230V AC / 50Hz |
| Apparent consumption: | 1.1 VA |
| Dissipated power: | 0.8W |
| Tolerance of supply voltage: | 9.85 |
| Connection: | 4 Pin Click Flow Male / Female Connector |
| Output | |
| Resistive load: | 160W |
| Capacitive lod: | 160W |
| Inductive load: | 160W |
| Output | |
| Packet from transmitter: | 868 MHz |
| Manual control: | PROG (ON/OFF), external button |
| Range in open space: | up to 160M |
| Other data | |
| Operational temperature: | -20 °C to +35 °C |
| Operational position: | any |
| Mounting: | 35mm deep enclosure (plastic) |
| Protection degree: | IP 30 |
| Overvoltage category: | III. |
| Pollution level: | 2 |
| Output wires: | 4 x 0.75 mm2 |
| Output wire length: | 90 mm |
| Dimensions: | 260.5 x 52.2 x 25.3mm |
| Weight: | 140g |
| Applying standards: | EN50491-1, EN5049102, EN50491-3
EN50491-4-1, EN50491-5-1, EN50491-5-2
ETSI, EN 301489-3, ETSI EN 300220-2 EN 60669-2-1 |
